Yesterday I was looking around on the inter-webs for a Scala project that was “iBatis” like, but more Scala oriented. I found some cool stuff (ScalaQL, and scala-sql-dsl for example) but nothing quite what I was looking for.

I kind of chewed on what exactly it was that I was looking for and this is my 10k/foot feature list:

Ability to define the underlying data store in a DSL that can be understood by Scala
Ability to map Scala classes to JDBC results by binding to artifacts of the data store

This is more or less what iBatis accomplishes with xml (now annotations) and a bunch of reflection. I’d like to see it done without XML and minimal reflection.

That sent me down the rabbit hole on how exactly one goes about defining a DSL in scala. I re-read chapter 31 in Programming in Scala. I also read chapter 11 in Programming Scala. Then I took a stab at writing a parser combinator for a very, very small subset of the “CREATE TABLE” DDL syntax for SQL.

import scala.util.parsing.combinator._

class TableDdlParser extends JavaTokenParsers {

  def tables: Parser[Map[String, Any]] = rep(table) ^^ { Map() ++ _ }

  def table: Parser[(String,Any)] =
    ("TABLE" ~ tableName ~ columns
       ^^ { case "TABLE" ~ tableName ~ tableContents => (tableName,tableContents) })

  def tableName: Parser[String] = ident ^^ { case ident => ident }

  def columns: Parser[Map[String, Any]] = "("~> repsep(column, ",") <~")" ^^ { Map() ++ _ }

  def column: Parser[(String,Any)] =
    columnName ~ dataType ^^ { case columnName ~ dataType => (columnName,dataType) }

  def columnName: Parser[String] = ident ^^ { case ident => ident }

  def dataType: Parser[Any] = "VARCHAR" | "INTEGER"

}

object TableDdlParserRunner extends TableDdlParser {

  def main(args: Array[String]) {
    val input =
      """TABLE person (first_name VARCHAR, last_name VARCHAR, age INTEGER)
         TABLE place (city VARCHAR, state VARCHAR)"""
    println(parseAll(tables,input))
  }

}

Here is the output

[2.51] parsed:
Map(person -> Map(first_name -> VARCHAR,
                  last_name -> VARCHAR,
                  age -> INTEGER),
    place -> Map(city -> VARCHAR,
                 state -> VARCHAR))

This experiment only supports two data types (VARCHAR and INTEGER), without any of the other metadata that is required for those types. I just wanted a feel for how hard it would be to write and didn’t want to get bogged down in the details. It turned out to be quite a bit easier than I thought it would be.

Next up is to figure out the best way to map this DDL information to a scala class (If I don’t get distracted by something else first).

In the "code club" / "dojo" or whatever you want to call it that Ben (aka Johnny Coder) organized we have been learning about Scala the last few weeks. I have been puttering with Scala on my own for about a year now, and it has been fun to engage with other folk in the learning process. We have mostly been doing a mix of Project Euler and the S-99 problems as exercises. Those problems are fun, but they don’t really reflect the kind of day to day programming tasks that I am usually engaged in.

To scratch that slightly more practical itch, I decided to see how well Scala fits in with other tools in the Java ecosystem. The Java ecosystem being broad, and my Scala kung fu being not that strong, all I have are some possibly interesting bits I discovered while trying to get Scala and RESTEasy working together. I picked RESTEasy because in the middle of reading RESTful Java with JAX-RS.

I started off with an existing example project from chapter 11 in the RESTEasy book. I added the Scala plugin to the maven build, and I was off.

The first class I converted over was a JAXB annotated class com.restfully.shop.domain.Customer

I ran into a few things that caused me problems. The first was this compiler message:

"';' expected but ',' found"

At the @XMLType annotation line. The resolution was to switch from using the Array literal "{}" Java syntax to the Scala Array object.

I also got a JAXB runtime error during the JUnit tests:

....
Caused by: com.sun.xml.bind.v2.runtime.IllegalAnnotationsException: 15 counts of IllegalAnnotationExceptions
There are two properties named ....

I resolved that by using the @XmlAccessorType(XmlAccessType.FIELD) annotation.

For compatibility with the existing code that expected Java Bean style property access, I added the @BeanProperty annotation. The annotation causes Scala to automatically generate get/set methods.

Here is the java version of Customer:

package com.restfully.shop.domain;

import javax.xml.bind.annotation.XmlAttribute;
import javax.xml.bind.annotation.XmlElement;
import javax.xml.bind.annotation.XmlRootElement;
import javax.xml.bind.annotation.XmlType;

@XmlRootElement(name = "customer")
@XmlType(propOrder = {"firstName", "lastName", "street", "city", "state", "zip", "country"})
public class Customer
{
   private int id;
   private String firstName;
   private String lastName;
   private String street;
   private String city;
   private String state;
   private String zip;
   private String country;

   @XmlAttribute
   public int getId()
   {
      return id;
   }

   public void setId(int id)
   {
      this.id = id;
   }

   @XmlElement(name = "first-name")
   public String getFirstName()
   {
      return firstName;
   }

   public void setFirstName(String firstName)
   {
      this.firstName = firstName;
   }

   @XmlElement(name = "last-name")
   public String getLastName()
   {
      return lastName;
   }

   public void setLastName(String lastName)
   {
      this.lastName = lastName;
   }

   @XmlElement
   public String getStreet()
   {
      return street;
   }

   public void setStreet(String street)
   {
      this.street = street;
   }

   @XmlElement
   public String getCity()
   {
      return city;
   }

   public void setCity(String city)
   {
      this.city = city;
   }

   @XmlElement
   public String getState()
   {
      return state;
   }

   public void setState(String state)
   {
      this.state = state;
   }

   @XmlElement
   public String getZip()
   {
      return zip;
   }

   public void setZip(String zip)
   {
      this.zip = zip;
   }

   @XmlElement
   public String getCountry()
   {
      return country;
   }

   public void setCountry(String country)
   {
      this.country = country;
   }

   @Override
   public String toString()
   {
      return "Customer{" +
              "id=" + id +
              ", firstName='" + firstName + '\'' +
              ", lastName='" + lastName + '\'' +
              ", street='" + street + '\'' +
              ", city='" + city + '\'' +
              ", state='" + state + '\'' +
              ", zip='" + zip + '\'' +
              ", country='" + country + '\'' +
              '}';
   }
}

Here is my Scala conversion of Customer:

package com.restfully.shop.domain

import javax.xml.bind.annotation.XmlAttribute
import javax.xml.bind.annotation.XmlElement
import javax.xml.bind.annotation.XmlRootElement
import javax.xml.bind.annotation.XmlType
import javax.xml.bind.annotation.XmlAccessorType
import javax.xml.bind.annotation.XmlAccessType

import scala.reflect.BeanProperty

@XmlRootElement(name = "customer")
@XmlType(propOrder = Array("firstName", "lastName", "street", "city", "state", "zip", "country"))
@XmlAccessorType(XmlAccessType.FIELD)
class Customer {

   @XmlAttribute
   @BeanProperty
   var id: Int = _

   @XmlElement(name = "first-name")
   @BeanProperty
   var firstName: String = _

   @XmlElement(name = "last-name")
   @BeanProperty
   var lastName: String = _

   @XmlElement
   @BeanProperty
   var street: String = _

   @XmlElement
   @BeanProperty
   var city: String = _

   @XmlElement
   @BeanProperty
   var state: String = _

   @XmlElement
   @BeanProperty
   var zip: String = _

   @XmlElement
   @BeanProperty
   var country: String = _

   override def toString =
    "Customer{" +
    "id=" + id +
    ", firstName='" + firstName + '\'' +
    ", lastName='" + lastName + '\'' +
    ", street='" + street + '\'' +
    ", city='" + city + '\'' +
    ", state='" + state + '\'' +
    ", zip='" + zip + '\'' +
    ", country='" + country + '\'' +
    '}'

}

The next class I converted was com.restfully.shop.domain.Customers

This conversion was very similar, but it was dealing with collections. I found that Scala 2.8 has a new object scala.collection.JavaConversions that contains many implicit conversion for Java collections.

Here is the Java version of Customers:

package com.restfully.shop.domain;

import javax.xml.bind.annotation.XmlElementRef;
import javax.xml.bind.annotation.XmlRootElement;
import javax.xml.bind.annotation.XmlTransient;
import java.util.ArrayList;
import java.util.Collection;
import java.util.List;

/**
 * @author Bill Burke
 * @version $Revision: 1 $
 */
@XmlRootElement(name = "customers")
public class Customers
{
   protected Collection customers = new ArrayList();
   protected List links;

   @XmlElementRef
   public Collection getCustomers()
   {
      return customers;
   }

   public void setCustomers(Collection customers)
   {
      this.customers = customers;
   }

   @XmlElementRef
   public List getLinks()
   {
      return links;
   }

   public void setLinks(List links)
   {
      this.links = links;
   }

   @XmlTransient
   public String getNext()
   {
      if (links == null) return null;
      for (Link link : links)
      {
         if ("next".equals(link.getRelationship())) return link.getHref();
      }
      return null;
   }

   @XmlTransient
   public String getPrevious()
   {
      if (links == null) return null;
      for (Link link : links)
      {
         if ("previous".equals(link.getRelationship())) return link.getHref();
      }
      return null;
   }

}

Here is my Scala conversion of Customers:

package com.restfully.shop.domain

import java.util.{ArrayList => JArrayList}
import java.util.{Collection => JCollection}
import java.util.{List => JList}

import javax.xml.bind.annotation.XmlElementRef
import javax.xml.bind.annotation.XmlRootElement
import javax.xml.bind.annotation.XmlTransient
import javax.xml.bind.annotation.XmlAccessorType
import javax.xml.bind.annotation.XmlAccessType

import scala.collection.Iterable
import scala.collection.JavaConversions._
import scala.collection.mutable.Buffer

@XmlRootElement(name = "customers")
@XmlAccessorType(XmlAccessType.PROPERTY)
class Customers {

  var customers = Iterable[Customer]()
  var links: Buffer[Link] = Buffer()

  @XmlElementRef
  def getCustomers: JCollection[Customer] = customers
  def setCustomers(customers: JCollection[Customer]) = {
    this.customers = customers
  }

  @XmlElementRef
  def getLinks: JList[Link] = links
  def setLinks(links: JList[Link]) = {
    this.links = links
  }

  @XmlTransient
  def getNext(): String = findHref("next")

  @XmlTransient
  def getPrevious(): String = findHref("previous")

  private def findHref(rname: String): String = {
    val rel = links.filter(_.getRelationship == rname)
    rel match {
      case Buffer() => null
      case _        => rel.head.getHref
    }
  }

}

That’s about as far as I got this weekend. I guess I was actually mostly working with JAXB this time. The same example code has JPA as was as JAX-RS, and I’m going to try and convert the entire project to Scala, and if I do, I’ll upload it to BitBucket.
